Denso Iridium Power Spark Plug - 067700-8701
Contact Us
Share this product on Socials
Regular price
$11.70
Regular price
-22%
$15.00
Sale price
$11.70
Description
Spark plugs are sold per piece.
Specifications:
Manufacturer: Denso
Reference Number: 067700-8701
Spark Plug Type: Iridium Power IQ16
Heat Rating: 16
Thread Diameter: 14mm
Thread Length: 19mm
Width Across Hexagon Flats:16mm
Electrode Type: Crimped Nut
IQ series
IQ16. IQ20. IQ22. IQ24. IQ27. IQ31. IQ34
- Mainly used for cars.
- Dia. 14 mm ×L19 mm length type.
- IQ22 and above are for tuned engines, with a spark gap of 0.8 mm.
- IRIDIUM TOUGH VQ16, VQ20, and VQ22 are also on sale.
For drivers that care about performance.
By using a 0.4mm diameter iridium alloy center electrode and a special ground electrode, IRIDIUM POWER realizes spark performance unseen until now. It steadily gives a high level of response under a variety of driving conditions. The result? Increased acceleration and torque compared to regular plugs.
Construction:
1- Specifications Include Terminal
A terminal nut is attached that fits with most of the world’s spark plug cables. Please remove the nut for installations that do not require one. (The terminal nuts on the IWM and IK-G types are solid parts and cannot be removed.)
2- Built-in, Highly Reliable Resistor
All IRIDIUM POWER plugs include a highly reliable, 5,000 ohm monolithic resistor specification to reduce electromagnetic noise that may affect electronic devices. (For all plug types)
3- Highly Corrosion Resistant, Burnished Nickel Plating
The plug housing is plated with burnished nickel, the same as plugs used for racing. It is highly resistant to corrosion and rust even while touring in continually rainy weather and during motocross events. (Low-heat range types excluded)
4- 360° Laser Welding
The process used to mount the iridium tip is a highly reliable “All-around Laser Welding” process that is able to withstand all kinds of driving conditions. (For all plug types)
5- Projected Center Electrode
In order to improve ignitability, the center electrode protrudes more than with conventional type plugs. This improves both acceleration response time and performance.(Only with: IU31, IUH24, IUH27, IX22, IX24, IX27, IUF22, IUF24, IWF22, IWF24, IWF27, IW24, IW27, IW29, IW31, and IW34)
6- 0.4 mm Diameter Ultra-?ne Iridium Center Electrode
Using a new iridium alloy with a very high melting point, the tip of the electrode can be made very fine. This enables the reduction of voltage necessary to cause the spark, and greatly improves ignitability. Moreover, the special iridium alloy used was developed by DENSO
7- Taper-cut Ground Electrode
The tip of the ground electrode is cut to a fine taper to reduce the adverse effects of quenching, which greatly improves fuel ignitability. Also, because of the streamlined, taper-cut shape, the fuel-air mixture spreads more evenly in the gap, resulting in steady, reliable igniting of combustion.(excluding IUF27A, IUF31A, IU24A, IU27A, IU31A, IY24, IY27 & IY31)
8- U-Groove Ground Electrode
The U-shaped groove on the ground electrode insures that the inside surface area is large enough to generate the flame kernel. This shape enables lower voltage needed to cause the spark and results in excellent ignitability without increasing the size of the spark gap. (excluding IUF27A, IUF31A, IU24A and IU31A)
9- Insulator Projection
The projection of the insulator is optimally designed based on each plug's thermal value. This corresponds to requirements unique to thermal value, such as self-cleaning ability at lower thermal values, and heat resistance at higher thermal values. (For all plug types)
Specifications:
Manufacturer: Denso
Reference Number: 067700-8701
Spark Plug Type: Iridium Power IQ16
Heat Rating: 16
Thread Diameter: 14mm
Thread Length: 19mm
Width Across Hexagon Flats:16mm
Electrode Type: Crimped Nut
IQ series
IQ16. IQ20. IQ22. IQ24. IQ27. IQ31. IQ34
- Mainly used for cars.
- Dia. 14 mm ×L19 mm length type.
- IQ22 and above are for tuned engines, with a spark gap of 0.8 mm.
- IRIDIUM TOUGH VQ16, VQ20, and VQ22 are also on sale.
For drivers that care about performance.
By using a 0.4mm diameter iridium alloy center electrode and a special ground electrode, IRIDIUM POWER realizes spark performance unseen until now. It steadily gives a high level of response under a variety of driving conditions. The result? Increased acceleration and torque compared to regular plugs.
Construction:
1- Specifications Include Terminal
A terminal nut is attached that fits with most of the world’s spark plug cables. Please remove the nut for installations that do not require one. (The terminal nuts on the IWM and IK-G types are solid parts and cannot be removed.)
2- Built-in, Highly Reliable Resistor
All IRIDIUM POWER plugs include a highly reliable, 5,000 ohm monolithic resistor specification to reduce electromagnetic noise that may affect electronic devices. (For all plug types)
3- Highly Corrosion Resistant, Burnished Nickel Plating
The plug housing is plated with burnished nickel, the same as plugs used for racing. It is highly resistant to corrosion and rust even while touring in continually rainy weather and during motocross events. (Low-heat range types excluded)
4- 360° Laser Welding
The process used to mount the iridium tip is a highly reliable “All-around Laser Welding” process that is able to withstand all kinds of driving conditions. (For all plug types)
5- Projected Center Electrode
In order to improve ignitability, the center electrode protrudes more than with conventional type plugs. This improves both acceleration response time and performance.(Only with: IU31, IUH24, IUH27, IX22, IX24, IX27, IUF22, IUF24, IWF22, IWF24, IWF27, IW24, IW27, IW29, IW31, and IW34)
6- 0.4 mm Diameter Ultra-?ne Iridium Center Electrode
Using a new iridium alloy with a very high melting point, the tip of the electrode can be made very fine. This enables the reduction of voltage necessary to cause the spark, and greatly improves ignitability. Moreover, the special iridium alloy used was developed by DENSO
7- Taper-cut Ground Electrode
The tip of the ground electrode is cut to a fine taper to reduce the adverse effects of quenching, which greatly improves fuel ignitability. Also, because of the streamlined, taper-cut shape, the fuel-air mixture spreads more evenly in the gap, resulting in steady, reliable igniting of combustion.(excluding IUF27A, IUF31A, IU24A, IU27A, IU31A, IY24, IY27 & IY31)
8- U-Groove Ground Electrode
The U-shaped groove on the ground electrode insures that the inside surface area is large enough to generate the flame kernel. This shape enables lower voltage needed to cause the spark and results in excellent ignitability without increasing the size of the spark gap. (excluding IUF27A, IUF31A, IU24A and IU31A)
9- Insulator Projection
The projection of the insulator is optimally designed based on each plug's thermal value. This corresponds to requirements unique to thermal value, such as self-cleaning ability at lower thermal values, and heat resistance at higher thermal values. (For all plug types)
Taxes & Shipping
Taxes:
Singapore and Malaysia: All import taxes are included in our pricing.
Rest of the World: Other countries may have to pay their local import tax depending on your country's regulations.
Singapore and Malaysia: All import taxes are included in our pricing.
Rest of the World: Other countries may have to pay their local import tax depending on your country's regulations.
Fitting information
IQ series
IQ16. IQ20. IQ22. IQ24. IQ27. IQ31. IQ34
- Mainly used for cars.
- Dia. 14 mm ×L19 mm length type.
- IQ22 and above are for tuned engines, with a spark gap of 0.8 mm.
- IRIDIUM TOUGH VQ16, VQ20, and VQ22 are also on sale.
RZCREW Tech!!
Heat Value Conversion Table
| hot | < | - | - | - | - | > | Cold | |
| NGK | 5 | 6 | 7 | 8 | 9 | 10 | 10.5 | 11 |
| Denso | 16 | 20 | 22 | 24 | 27 | 31 | 32 | 34 |
| HKS | 25 | 30 | 35 | 40 | 45 | 50 | 52.5 | 55 |
