Denso Iridium Racing Spark Plug - 267700-1591
Contact Us
Share this product on Socials
Regular price
$27.50
Regular price
-21%
$35.00
Sale price
$27.50
Description
Spark plugs are sold per piece.
Specifications:
Manufacturer: Denso
Reference Number: 267700-1591
Spark Plug Type: Iridium Racing RU01-34
Heat Rating: 34
Thread Diameter: 10mm
Thread Length: 19mm
Width Across Hexagon Flats:16mm
Electrode Type: Removable
RU01
- Electrode Shape: C
- Height of plug 50mm
- U-E (SURFACE)
* Iridium center electrode, not an all-platinum ground electrode.
Electrode Shapes:
Improve acceleration and engine power with IRIDIUM RACING
It’s the age of iridium electrodes. Discover more acceleration with 0.4 mm DENSO Racing Plugs. DENSO would like you to try the 0.4 mm IRIDIUM RACING advantage.
Use IRIDIUM RACING and experience a ride like never before.
Construction:
1- Specifications Include Terminal
Included with the plug comes with a terminal nut compatible to the Nology Hot Wire and most plug cords around the world. Please remove for vehicle types that do not require terminals. (Some plugs have solid terminals. Please refer to the list.)
2- Built-in, Highly Reliable Resister
All IRIDIUM RACING plugs specify a resistor, and contain a highly reliable monolithic-type resistor that blocks noise that may affect electronic devices. (IW06 has no resistor.)
3- Highly Corrosion Resistant, Burnished Nickel Plating
Burnished nickel plating on the housing, a high level of corrosion resistance has been realized. Also, because the amount on the threads is low, the damage to the female thread in the cylinder is reduced.
4- 0.4 mm Diameter Ultra-Fine Iridium Center Electrode
The center electrode tip is able to be made fine using a new iridium alloy with a high melting point. The required voltage is reduced, and ignitability is improved greatly.
5- All-platinum Ground Electrode
Compared to the nickel alloy used in conventional spark plugs, the high melting point of platinum will reduce such problems as ground electrode melting and wear. Also, the 0.8mm platinum alloy is welded on and gapped without any bending, reducing residual stress and increasing durability.
6- Insulators for Racing
By using a new, strengthened insulator which was developed during numerous and repeated testing during racing trials, strength is improved by 20%.
7- Spark Cleaning Pocket
Between the center electrode and the insulator, a small pocket has been opened around the tip clearance. When there is carbon fouling or deposition, this part will discharge and burn off the carbon, restoring electrical resistance. This technology is patented by DENSO (Japan Patent No. 2727558).
8- Silicone Oil Coating
During the start of the race, non-starting from carbon fouling and carbon deposits can be fatal. To stop this, the insulator has been coated with a silicone coating. Using the water repellency of silicone, the insulator surface is isolated from moisture and carbon, preventing a decrease in resistance.
9- 360° Laser Welding
The process used to join the iridium tip is a highly reliable “All-around Laser Welding” process that is able to withstand various kinds of driving conditions.
Specifications:
Manufacturer: Denso
Reference Number: 267700-1591
Spark Plug Type: Iridium Racing RU01-34
Heat Rating: 34
Thread Diameter: 10mm
Thread Length: 19mm
Width Across Hexagon Flats:16mm
Electrode Type: Removable
RU01
- Electrode Shape: C
- Height of plug 50mm
- U-E (SURFACE)
* Iridium center electrode, not an all-platinum ground electrode.
Electrode Shapes:
Improve acceleration and engine power with IRIDIUM RACING
It’s the age of iridium electrodes. Discover more acceleration with 0.4 mm DENSO Racing Plugs. DENSO would like you to try the 0.4 mm IRIDIUM RACING advantage.
Use IRIDIUM RACING and experience a ride like never before.
Construction:
1- Specifications Include TerminalIncluded with the plug comes with a terminal nut compatible to the Nology Hot Wire and most plug cords around the world. Please remove for vehicle types that do not require terminals. (Some plugs have solid terminals. Please refer to the list.)
2- Built-in, Highly Reliable Resister
All IRIDIUM RACING plugs specify a resistor, and contain a highly reliable monolithic-type resistor that blocks noise that may affect electronic devices. (IW06 has no resistor.)
3- Highly Corrosion Resistant, Burnished Nickel Plating
Burnished nickel plating on the housing, a high level of corrosion resistance has been realized. Also, because the amount on the threads is low, the damage to the female thread in the cylinder is reduced.
4- 0.4 mm Diameter Ultra-Fine Iridium Center Electrode
The center electrode tip is able to be made fine using a new iridium alloy with a high melting point. The required voltage is reduced, and ignitability is improved greatly.
5- All-platinum Ground Electrode
Compared to the nickel alloy used in conventional spark plugs, the high melting point of platinum will reduce such problems as ground electrode melting and wear. Also, the 0.8mm platinum alloy is welded on and gapped without any bending, reducing residual stress and increasing durability.
6- Insulators for Racing
By using a new, strengthened insulator which was developed during numerous and repeated testing during racing trials, strength is improved by 20%.
7- Spark Cleaning Pocket
Between the center electrode and the insulator, a small pocket has been opened around the tip clearance. When there is carbon fouling or deposition, this part will discharge and burn off the carbon, restoring electrical resistance. This technology is patented by DENSO (Japan Patent No. 2727558).
8- Silicone Oil Coating
During the start of the race, non-starting from carbon fouling and carbon deposits can be fatal. To stop this, the insulator has been coated with a silicone coating. Using the water repellency of silicone, the insulator surface is isolated from moisture and carbon, preventing a decrease in resistance.
9- 360° Laser Welding
The process used to join the iridium tip is a highly reliable “All-around Laser Welding” process that is able to withstand various kinds of driving conditions.
Taxes & Shipping
Taxes:
Singapore and Malaysia: All import taxes are included in our pricing.
Rest of the World: Other countries may have to pay their local import tax depending on your country's regulations.
Singapore and Malaysia: All import taxes are included in our pricing.
Rest of the World: Other countries may have to pay their local import tax depending on your country's regulations.
Fitting information
RU01
- Electrode Shape: C
- Height of plug 50mm
- U-E (SURFACE)
* Iridium center electrode, not an all-platinum ground electrode.
Electrode Shapes:
RZCREW Tech!!
Heat Value Conversion Table
| hot | < | - | - | - | - | > | Cold | |
| NGK | 5 | 6 | 7 | 8 | 9 | 10 | 10.5 | 11 |
| Denso | 16 | 20 | 22 | 24 | 27 | 31 | 32 | 34 |
| HKS | 25 | 30 | 35 | 40 | 45 | 50 | 52.5 | 55 |
